Capabilities
We’ve been Chicagoland’s leading custom cable experts since 1988.
Our team is ready to assist in every stage of your product development and provide the right solution at the right price.
Our advantages include:
- Trained and qualified staff
- Early design review
- Reverse engineering
- Prototype design
- Quick turn around
- Engineer purchase hours available
Solutions:
Cable & terminination types:
- Tailored to Your Specifications: We create cables according to your precise drawings, ensuring they meet your exact needs.
- Custom Lengths: Our cables are made to the exact length you require, tailored for your specific applications.
- Pre-Kitted Parts and Cables: We can pre-kit parts and cables, so they are ready to use upon arrival, saving you time and simplifying your organization process.
- Personalized Packaging: We offer packaging solutions that suit your project needs, including cost-effective options and suggestions for optimal project handling.
- Custom Labeling: We can label your wires and cables according to your specific requirements for easy identification and organization.
- Custom Bundling: We bundle cables using tie wraps, woven braid, tape, heat shrink tubing, and sleeving, available in various lengths and configurations.
- Coax Cables
- Wire Harnesses
- Circular/Power Cables
- Ribbon Cables
- Grounding Straps
- D-Sub and RS232 Cables
- MIL-Spec Assemblies
- Modular Patch Cords
- Telco & Hydra Cables
Adapters - Solder
- IDC
- Splice
- Crimp and Poke
- Screw Type
Quality incoming inspection
All new components will undergo a thorough inspection against the manufacturer drawing. We also validate the component meets the customer drawing/specification.
Operator training
Employees are trained and/or familiar with IPC/WHMA-A-620 standard. IPC/WHMA-A-620 is the standard for cable and wire harness assemblies which defines acceptable guidelines for operating machines, soldering, and crimp quality.
100% continuity testing
Finished goods are all tested for low voltage continuity using manufacturing mating connectors, when available. Manufacturing also has the capability to test Hi-pot voltage as well as active components such as diodes, capacitors, and resistors.
Crimp testing
There are two ways to validate a proper crimp terminal. One method is a Pull Test between the wire and its specified terminal. Another method is a crimp height inspection, both methods will be measured and documented per the manufacturer’s specification.
QC 1st inspection
Every new production release must be submitted to QC for approval before releasing to Production. When a 1st piece is approved, QC personnel will sign a green acceptance tag which details customer part number and work order.
First Article Approval Process (FAI)
Customer purchase order will specify the First Article requirements. We have the capability to provide a simple first article which entails dimensional results and balloon drawing. Some first articles will require extensive plans such as the PPAP part approval process.
Prototypes
Prototypes or a short production run is a great way to ensure finished product meets customers fit, form, and function. This also allows production to identify process/design flaws and correct them before a production run.
Quality in-process inspection
In-process inspections are done throughout the process from wire processing to crimping dept and finally manufacturing process. These visual and dimensional inspections are performed and noted on production work order and scanned into the system.
Product traceability
All finished goods products can be fully traced back to the supplier.
